4000 Series

  • Kezdőlap
  • Generators Engine
  • 4000 Series
Previous Next
  • Presentation
  • Tehnical details
  • Photo Gallery

Presentation

Specifications

The 6, 8, 12 and 16 cylinder Perkins 4000 Series gives you the versatility you need in today’s power generation market. The range’s diesel ElectropaK engines/Electro Units deliver 750-2500 kVA and are supplied with or without radiator and air cleaner. This engine has proven reliability in prime and standby installations in all of the key sectors, such as manufacturing facilities, hospitals, and data centers. The 4008 engines have exceptional power-to-weight ratios and compact designs, making them simple to transport and install.
Dependable power

• Individual 4 valve cylinder heads giving optimized gas flows
• Unit fuel injectors ensure ultra fine fuel atomization and hence controlled rapid combustion
• Commonality of components with other engines in the 4000 Series family for reduced stocking levels
• Capable emissions of 1/2 TA Luft (1986)

Optional equipment

Options for your 4008 range diesel engines include:

• Tropical radiator, including water pipes, clips and hoses, fan, fan guards and bolts
• Twin heavy-duty air cleaners – paper element with pre-cleaner
• Changeover lubrication oil filter
• Changeover fuel oil filter
• Immersion heater with thermostat
• Air starters
• Instrument panel

ElectropaK diesel
The ElectropaK diesel engines in the 4012 range come complete with radiator and air cleaner. Models in the range are either turbocharged and air-to-air chargecooled or turbocharged and air-to-water chargecooled.

Economy
Economic and durable, the engines have excellent power-to-weight ratios, as well as outstanding load acceptance and improved emissions. Commonality of components with other engines in the 4000 Series makes replacing parts or upgrading an easy process

Optional equipment
Options for your 4016 range diesel engines include: • Tropical radiator, including water pipes, clips and hoses, fan, fan guards and belts
• Immersion heater with thermostat

Tehnical details

Model Power (kWm) Autonomy (he) Power (kVA) Emissions Specifications sheets
4006-23TAG 501 – 795 480 – 720 600 – 900 It does not comply with the emission regulations Data sheet
4008TAG 606 – 947 555 – 1000 694 – 1100 It does not comply with the emission regulations Data sheet
4008-30TAG 632 – 1055 6000 – 1000 750 – 1250 It does not comply with the emission regulations Data sheet
4012-46TWG 833 – 1342 791 – 1280 989 – 1600 It does not comply with the emission regulations Data sheet
4012-46TAG 842 – 1583 791 – 1500 898 – 1875 It does not comply with the emission regulations Data sheet
4016TAG 1219 – 1886 1170 – 1800 1463 – 2250 It does not comply with the emission regulations Data sheet
4016-61TRG 1179 – 2083 1120 – 2000 1400 – 2500 It does not comply with the emission regulations Data sheet
Technical specification:
  • Air inlet system
  • Mounted air filter and turbochargers
  • Cooling system
  • Two twin thermostats
  • Electrical equipment
  • 24 volt starter motor
  • 24 volt alternator
  • ECM mounted on engine block
  • Flywheels and flywheel housing
  • SAE 00 flywheel housing, SAE J620 size 18 flywheel
  • Fuel system
  • Oil system
